Name: Water Network Structure

Display Field: PROJECTNAME

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description:

Copyright Text: Okaloosa County W&S GIS Department

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1247625.9182341397
YMin: 514091.65539997816
XMax: 1367027.2132237256
YMax: 660996.5420358181
Spatial Reference: 102660  (2238)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: TYPE
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: ST
  Label: Storage Tank
  Description: N/A
  Symbol:

• Value: ESF
  Label: Enclosed Storage Facility
  Description: N/A
  Symbol:

• Value: MW
  Label: Monitoring Well
  Description: N/A
  Symbol:

• Value: PW
  Label: Production Well
  Description: N/A
  Symbol:

Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: FID )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 25 , Coded Values: [ESF: Enclosed Storage Facility] , [JC: Junction Chamber] , [MS: Meter Station] , ...8 more... )
• NETWORKUSEAGE ( type: esriFieldTypeString, alias: NETWORKUSEAGE, length: 20 , Coded Values: [EFF: Effluent Outfall] , [OVFL: Over Flow] , [POT: Potable Water] , ...6 more... )
• INSTALLDATE ( type: esriFieldTypeSmallInteger, alias: INSTALLDATE )
• OPERATIONALDATE ( type: esriFieldTypeSmallInteger, alias: OPERATIONALDATE )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 20 )
• LOCATION ( type: esriFieldTypeString, alias: LOCATION, length: 20 )
• ROTATION ( type: esriFieldTypeDouble, alias: ROTATION )
• REFERENCEID ( type: esriFieldTypeString, alias: REFERENCEID, length: 20 )
• DISTRICT ( type: esriFieldTypeString, alias: DISTRICT, length: 20 , Coded Values: [D1: District 1] , [D2: District 2] , [D3: District 3] , ...4 more... )
• ADMINIAREA ( type: esriFieldTypeString, alias: ADMINAREA, length: 20 , Coded Values: [CITY: Municipality] , [EAST: East County] , [EGLIN: Eglin AFB] , ...8 more... )
• LIFECYCLESTATUS ( type: esriFieldTypeString, alias: LIFECYCLESTATUS, length: 20 , Coded Values: [PROP: Proposed] , [ACT: Active] , [ABN: Abandon] , ...2 more... )
• ANCILLARYROLE ( type: esriFieldTypeSmallInteger, alias: ANCILLARYROLE )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: ENABLED , Coded Values: [0: False] , [1: True] )
• SCANNEDIMAGE ( type: esriFieldTypeString, alias: SCANNEDIMAGE, length: 20 )
• PROJECTNAME ( type: esriFieldTypeString, alias: PROJECTNAME, length: 150 )
• NOTES ( type: esriFieldTypeString, alias: NOTES, length: 150 )
• LATITUDE ( type: esriFieldTypeString, alias: LAT, length: 100 )
• LONGITUDE ( type: esriFieldTypeString, alias: LONG, length: 100 )
• Create_By ( type: esriFieldTypeString, alias: Create_By, length: 255 )
• Create_Date ( type: esriFieldTypeDate, alias: Create_Date, length: 8 )
• Edit_By ( type: esriFieldTypeString, alias: Edit_By, length: 255 )
• Edit_Date ( type: esriFieldTypeDate, alias: Edit_Date, length: 8 )
• AccCode ( type: esriFieldTypeString, alias: CODE, length: 50 , Coded Values: [CAD: CAD data deliverable] , [COGO: Coordinate Geometry] , [DIG: Heads up digitalizing] , ...6 more... )
• STRUCTURENAME ( type: esriFieldTypeString, alias: STRUCTURENAME, length: 50 )
• ID_TXT ( type: esriFieldTypeString, alias: ID_TXT, length: 255 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )

Supported Operations:   Query   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
